Semi-automatic plate change
Motor-driven plate adjustment
Environment-friendly
Main parameters
|
Printing speed
|
IPH
|
3000-10000
|
|
Max. paper size
|
mm
|
483×640
|
|
Min. paper size
|
mm
|
210×250
|
|
Max. printing area
|
mm
|
460×635
|
|
Max. printing area
|
mm
|
0.04-0.60
|
|
Plate size
|
mm
|
505×645
|
|
Plate+packing thickness
|
mm
|
0.42 *
|
|
Blanket size
|
mm
|
585×650
|
|
Blanket+packing thickness
|
mm
|
1.9
|
|
Feeding capability
|
mm
|
800
|
|
Delivery capability
|
mm
|
500
|
|
bite
|
mm
|
4-6
|
|
Bite margin
|
mm
|
8-9
|
|
horizontal plate adjustment range
|
mm
|
-1~+1
|
|
vertical plate adjustment range
|
mm
|
-1.96~+0.65
|
|
Main power
|
Kw
|
11
|
|
Machine dimension
|
mm
|
6000×2600×1800
|
|
Machine weight
|
Kg
|
10800
|
Configuration
|
Continuous alcohol dampening
|
Semi-automatic plate change
|
Down swing feeder
|
Closed-loop horizontal motor-driven plate adjustment
|
|
Closed-loop vertical motor-driven plate adjustment
|
Closed-loop diagonal motor-driven plate adjustment
|
Remote ink control
|
Remote water control
|
|
Pneumatic ink supply
|
Pneumatic water supply
|
Pneumatic braking
|
0.15mm thin plate
|
|
Medium lengthened delivery
|
Inspection table(10.4")
|
Sheet deculer
|
Vacuum braking rollers
|
|
Powder spray
|
Blow fans
|
Environment-friendly fountain
|
CCD plate punch(optional)
|
|
UV printing(optional）
|
Lever-style parted ink fountain
|
MDS ink remote control system(optional)
|
CIP3 separation pre-setting system(optional)
|
